Props

A prop is one named attribute on an element — children, variant, open, onClick. You fill it with a literal, a {{…}} expression, or (on a function slot) a function call. You never send the whole props object.

Which keys exist is not “whatever React or HTML accepts.” A slot is settable only if that kind declares it. Primitive declarations are per kind. User-component declarations are that component’s fields. An extra key is Unrecognized key.

See Registry for kinds. This page is how you set values.

What is on a slot

Every kind also accepts global fields:

data-* keys (data-state, data-favorite, …) are allowed by shape on every kind — they are not listed per kind.

A slot’s type (text, boolean, function, …) is a field type. The validator checks the stored value (literal or expression string). The renderer evaluates a whole {{…}} to its native type at render.

Set/unset, never replace

update_props takes a command list. Last write wins for duplicate keys in one call.

Do not send every current prop. A full-object replace would force every value on every call — keys get dropped, strings get rewritten. Send only the slots you are changing.

update_element uses the same command shape for node fields (kind, repeatable, repeatSource, renderIf) — not for props. children, href, src, placeholder, instance fields, expressions, and function bindings are update_props.

Create vs update

add_element.props is an array of { key, value } where value is only string, number, or boolean.

A whole {{…}} binding is a string, so it can ride a text/boolean slot on create. Objects cannot — function event bindings, nested records, arrays. Set those with update_props after the element exists. add_elements is the same primitive-value rule; Component kinds may also pass instanceProps as { key, value } entries, folded into the same record.

Read current values with inspect_element. It returns stored props (nulls stripped), not the kind’s schema.

Expressions in string slots

Anywhere a slot stores a string (or a boolean/number that also accepts a string), a whole {{…}} is an expression evaluated at render.

A whole binding ("{{stores.rsvp.modalOpen}}") is stored as an expression. Mixed text ("Hello {{stores.user.name}}") stays a string and interpolates — it is not upgraded to an expression object.

Function, component, and element slots do not accept a bare {{…}} — they store a binding record. Boolean/text/object/array slots do.

Declare every store field you bind, with a defaultValue. An undeclared field is undefined on first paint and flips controlled inputs.

Action bindings on event props

An event slot (onClick, onChange, onValueChange, onOpenChange, onSubmit, …) is a function type. The stored value is a call:

Full catalog: Action. One call per element slot — sequences live on a store action, pointed at from N slots.

This is an object, so it goes through update_props, not add_element.props.

For Dialog / Switch / Select, round-trip with "{{event}}" on onOpenChange / onValueChange / onCheckedChange.

Pointer events (onClick, onMouseEnter, onMouseLeave) are not global. They are declared only on kinds whose wrapper forwards them to the node the user actually clicks. A handler on a wrapper that never fires is worse than missing.

Why most HTML / React props are not settable

The vendor component still accepts native attributes. The builder does not persist them unless they are fields.

1. Strict schema. Extra keys fail. MCP, the prop editor, and insert all go through that schema.
2. Opt-in DOM surface. Coss wrappers inherit hundreds of HTML attributes. Declaring all of them on every kind would drown the props form. Input-ish kinds share a text-entry bundle, and clickable kinds share pointer events — still an explicit list, not a global.
3. Names must be real vendor props — the reverse is false. A declared name exists on the component. Not every vendor prop is declared.
4. Some vendor props are deferred. Out-refs such as actionsRef and inputRef have no authorable value yet.
5. HTML div is not a grab-bag. A div has children plus globals. onClick, tabIndex, title, hidden are not slots. Put a click on a Button (or an a), not a div.
6. Native form attributes that fight the hook flow are omitted. coss Form declares errors, onSubmit, validationMode — not HTML action / method. Those would trigger a full-page POST.

If update_props rejects a key, that prop is not declared for the kind. Do not try to smuggle it through className or a data-* except where a data attribute is actually what you mean.

Examples

Component instances

On a Component-kind node, slots are that component’s fields plus globals. list_components then load_component_outline for the schema. Set instance values with update_props (or instanceProps on add_elements).

Inside the definition, bind_prop writes {{props.<key>}} onto an inner element’s slot:

You can set the same expression yourself with update_props. bind_prop is the dedicated form. set_props_schema replaces the whole fields array — not incremental.

MCP tools

Gotchas

• Commands, not a blob. Merge is server-side. Re-sending the whole props object is how keys vanish.
• Unrecognized key. The kind does not declare it. Check Registry, not the React types.
• onClick is not universal. Button yes; Input no; div no.
• functionId, not a JS body. The element stores a pointer. Bodies live on store code-actions.
• {{event}} vs {{event.target.value}}. Base UI change/open/checked handlers pass the value as the first argument. Native onChange still uses the DOM event.
• class is invalid. className only.
• aria-label is a DOM name, not an editor tag. Set it when the node has no accessible name of its own (icon-only button). Visible text already names the control — a second label overrides it in the accessibility tree.
